HomeBatteryLow VoltageLow Voltage Lithium Battery 48V 51.2V 200Ah 300Ah With Intelligent BMS
Basic Parameters
Detail Parameters

Low Voltage Lithium Battery 48V 51.2V 200Ah 300Ah With Intelligent BMS

Share:

  • 48V 200-300Ah high density Li-Ion batteries with advanced BMS for optimum performance and safety.
  • 48V-51.2V LiFePO4 batteries, 200-300Ah high capacity, intelligent BMS for safety & efficiency.
  • High capacity 48-51.2V Li-Ion batteries (200-300Ah) with advanced BMS for optimum performance and safety.
  • 200Ah-300Ah low voltage Li-Ion packs with advanced BMS for increased safety, efficiency and longevity in compact energy storage.
  • Versatile 51.2V LiFePO4 battery systems 200-300Ah with integrated BMS for reliable, scalable energy storage solutions.
  • 48V 200-300Ah high density Li-Ion batteries with advanced BMS for optimum performance and safety.
  • 48V-51.2V LiFePO4 batteries, 200-300Ah high capacity, intelligent BMS for safety & efficiency.
  • High capacity 48-51.2V Li-Ion batteries (200-300Ah) with advanced BMS for optimum performance and safety.
  • 200Ah-300Ah low voltage Li-Ion packs with advanced BMS for increased safety, efficiency and longevity in compact energy storage.
  • Versatile 51.2V LiFePO4 battery systems 200-300Ah with integrated BMS for reliable, scalable energy storage solutions.
  • 1. Core Product Overview
    Modular LiFePO4 systems (48V/51.2V, 100Ah-300Ah) offer scalable energy storage from 2.5kWh to 30kWh via a hot-swappable, plug-and-play design. Ideal for dynamic capacity expansion in residential, commercial and industrial applications.

    2. Advanced Technology & Features
    Smart BMS enables real-time monitoring of voltage, temperature and SOC/SOH with precision balancing. UL/IEC/CE certified rugged construction ensures 6,000+ cycles (80% DoD), Wi-Fi/App remote control and wall/stack mounting for harsh environments.

    3. Application versatility
    Optimised for solar/wind storage, telecom, industrial UPS and off-grid systems. High discharge efficiency and modularity support seamless integration in extreme conditions.

    4. Customisation & Future Readiness
    Tailored voltage/capacity configurations and hybrid system compatibility ensure minimal integration effort, long-term ROI and adaptability to evolving energy needs.
Download Inquire

FAQS

Q :

What is the maximum capacity achievable with stackable batteries?‌

A :

By linking multiple modules, systems can scale from 5kWh (single 100Ah unit) to 30kWh+ (stacked 300Ah units), depending on your energy needs.

Q :

Are these batteries compatible with existing solar/inverter setups?

A :

Yes, the 48V/51.2V standard voltage integrates seamlessly with most solar inverters, off-grid systems, and hybrid energy setups.

Q :

How does the smart BMS enhance safety?

A :

The BMS provides real-time protection against overcharge, over-discharge, short circuits, and temperature fluctuations, while balancing cells for optimal lifespan.

Q :

Can I monitor the system remotely?‌

A :

Yes, built-in Wi-Fi allows 24/7 monitoring via mobile app or web interface, tracking SOC, SOH, voltage, temperature, and system alerts.

Q :

What is the lifespan of these batteries?‌

A :

Designed for 6,000+ deep cycles at 80% DoD (Depth of Discharge), the LiFePO4 chemistry ensures 10+ years of reliable service under normal conditions.

Q :

Are the modules hot-swappable?

A :

Yes, the plug-and-play design allows adding or replacing modules.

Product Information

ModelLV-BST-L2.56Ba/5.12Aa
Nominal Voltage(Vdc)51.2
Nominal Capacity(Wh)2560/5120
Working Voltage Range(Vdc)44.8-56.16
Charge Voltage(Vdc)58.4
Nominal Charge/Discharge Current(A)25/50
Max.Charge/Discharge Current(A)50/100
Peak Current(A)100/200@3sec
Parallel Connection≤10 pcs/ ≤6 pcs
Cycle life6000 @ 80% DOD, 25°C / 0.5C
Structure
Dimension(mm)600*210*180/ 600*210*300
Weight(Kg)27/48
IP ratingIP65
InstallationStacked
Working Environment
Charge working temperature(℃)0~60
Discharge working temperature(℃)-20~60
Altitude(M)<2500
Humidity(RH)5~95%( w/o condensing)
Communication
Communication PortRS485,CAN
DisplaySOC status indicator, LED indicato
CertificationCB, IEC62619; CE-EMC, CE-GPSD, UKCA; UN38.3, MSDS
