Home Use 5-6KW Off-Grid Inverters For Reliable Solar Power Conversion​

Share:

  • 5-6KW high efficiency off-grid inverter for reliable home energy storage and stable solar power conversion in grid independent system
  • High performance 5-6KW grid-independent inverter with smart MPPT to optimize residential solar and storage solutions
  • 5-6kW Residential Off-Grid Inverters Ensure Stable Off-Grid Power Supply for Sustainable Energy Systems
  • 5-6kW off-grid inverter optimized for efficient home solar storage and off-grid power conversion in residential PV systems
  • 5-6KW high efficiency off-grid inverter for reliable home energy storage and stable solar power conversion in grid independent system
  • High performance 5-6KW grid-independent inverter with smart MPPT to optimize residential solar and storage solutions
  • 5-6kW Residential Off-Grid Inverters Ensure Stable Off-Grid Power Supply for Sustainable Energy Systems
  • 5-6kW off-grid inverter optimized for efficient home solar storage and off-grid power conversion in residential PV systems
  • 1. User-Friendly Outdoor Readability
    IP65-rated colorful touchscreen ensures clear operation and real-time monitoring in harsh weather (rain, dust) for seamless outdoor energy management.

    2. Rapid High-Current Charging
    135A max current enables fast battery charging/discharging, critical for emergency backup or high-power appliances in off-grid scenarios.

    3. Hybrid Generator Integration
    Stores excess diesel generator energy into batteries, reducing fuel waste and ensuring 24/7 power during low solar periods or outages.

    4. Robust Energy Resilience
    Combines solar, generator, and battery inputs for adaptive power redundancy in remote or disaster-prone areas with unstable resources.
Download Inquire

FAQS

Q :

Is the display usable in harsh outdoor conditions?

A :

IP65-rated touchscreen resists rain, dust, and extreme temps, ensuring clear visibility and control during storms or dusty environments.

Q :

How fast can the system charge batteries?

A :

135A max current enables rapid charging for high-demand appliances (e.g., power tools) or urgent backup needs in off-grid locations.

Q :

Can it store energy from a diesel generator?

A :

Yes, captures excess generator power to charge batteries, cutting fuel use and ensuring 24/7 supply during low solar or grid outages.

Q :

Does it handle unstable energy environments?

A :

Integrates solar, generator, and batteries for reliable power in disasters or remote areas with inconsistent energy resources.

Product Information

ModelSUN-3K
OG01LP1-24-EU-AM2		SUN-3.6K
OG01LP1-EU-AM2		SUN-5K
OG01LP1-EU-AM2		SUN-6K
Model OG01LP1-EU-AM2
Battery Input Data
Battery TypeLead-acid or Li-lonLead-acid or Li-lonLead-acid or Li-lonLead-acid or Li-lon
Battery Voltage Range (V)20~3040~6040~6040~60
Max. Charging Current (A)13090120135
Max. Discharging Current (A)13090120135
Charging Strategy for Li-ion BatterySelf-adaption to BMSSelf-adaption to BMSSelf-adaption to BMSSelf-adaption to BMS
Number of Battery Input1111
PV String Input Data
Max. PV Access Power (W)600072001000012000
Max. PV Input Power (W)4800576080009600
Max. PV Input Voltage (V)500500500500
Start-up Voltage (V)125125125125
PV Input Voltage(V)125-500125-500125-500125-500
MPPT Voltage Range(V)150-425150-425150-425150-425
Full Load MPPT Voltage Range(V)300-425300-425300-425300-425
Rated PV Input Voltage (V)370370370370
Max. Operating PV Input Current (A)1818+1818+1818+18
Max. Input Short-Circuit Current (A)2727+2727+2727+27
No.of MPP Trackers/No.of Strings MPP Tracker1/12/1+12/1+12/1+1
Max. Inverter Backfeed Current to The Array(A)0000
AC Output Data
Rated AC Output Power (VA/W)3000360050006000
Max. AC Output Power (VA/W)3000360050006000
Max. AC Output Current (A)13.115.721.826.1
Peak Power (W)2 times of rated power, 10s2 times of rated power, 10s2 times of rated power, 10s2 times of rated power, 10s
Rated Output Voltage (V)230230230230
Output TypeL+N+PEL+N+PEL+N+PEL+N+PE
Rated Output Frequency50Hz/ 50Hz50Hz/ 50Hz50Hz/ 50Hz50Hz/ 50Hz
Output Voltage WaveformPure Sine WavePure Sine WavePure Sine WavePure Sine Wave
Total Current Harmonic Distortion THDi＜3%＜3%＜3%＜3%
AC Input Date(Grid and Generator)
Rated Output Voltage (V)3000360050006000
Output Type230230230230
Rated Output Frequency50Hz/ 60Hz50Hz/ 60Hz50Hz/ 60Hz50Hz/ 60Hz
Output Voltage Waveform35353535
Total Current Harmonic Distortion THDi35353535
Efficiency
Max. Efficiency97.60%97.60%97.60%97.60%
Euro Efficiency96.50%96.50%96.50%96.50%
MPPT Efficiency＞99%＞99%＞99%＞99%
Equipment Protection
IntegratedDC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Insulation Impedance Detection, DC Switch		DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Insulation Impedance Detection, DC Switch		DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Insulation Impedance Detection, DC Switch		DC Reverse Polarity Protection, AC Output Overcurrent Protection, Thermal Protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Insulation Impedance Detection, DC Switch
Surge Protection LevelTYPE II(DC), TYPE II(AC)TYPE II(DC), TYPE II(AC)TYPE II(DC), TYPE II(AC)TYPE II(DC), TYPE II(AC)
Interface
LCD/LED DisplayLCDLCDLCDLCD
Communication InterfaceWIFI/RS485/CAN/BluetoothWIFI/RS485/CAN/BluetoothWIFI/RS485/CAN/BluetoothWIFI/RS485/CAN/Bluetooth
General Data
Max. Operating Frequency(Hz)200M200M200M200M
Operating Temperature Range (℃)-40 to +60℃, >45℃ Derating-40 to +60℃, >45℃ Derating-40 to +60℃, >45℃ Derating-40 to +60℃, >45℃ Derating
Permissible Ambient Humidity0-100%0-100%0-100%0-100%
Permissible Altitude3000m3000m3000m3000m
Noise (dB)<55<55<55<55
Ingress Protection(IP) RatingIP65IP65IP65IP65
Inverter TopologyNon-IsolatedNon-IsolatedNon-IsolatedNon-Isolated
Over Voltage CategoryOVC II(DC), OVC III(AC)OVC II(DC), OVC III(AC)OVC II(DC), OVC III(AC)OVC II(DC), OVC III(AC)
Cabinet Size (WxHxD mm)306x427.5x175.77 (Excluding Connectors and Brackets)306x427.5x175.77 (Excluding Connectors and Brackets)306x427.5x175.77 (Excluding Connectors and Brackets)306x427.5x175.77 (Excluding Connectors and Brackets)
Weight (kg)12.6512.6512.6512.65
Type of CoolingIntelligent Air CoolingIntelligent Air CoolingIntelligent Air CoolingIntelligent Air Cooling
WarrantyStandard 5 years, extended warrantyStandard 5 years, extended warrantyStandard 5 years, extended warrantyStandard 5 years, extended warranty
Safety / EMC StandardIEC62109-1/-2, EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4IEC62109-1/-2, EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4IEC62109-1/-2, EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4IEC62109-1/-2, EN61000-6-1, EN61000-6-2, EN61000-6-3, EN61000-6-4
