High voltage lithium battery 358.4~716.8V/280Ah for commercial use

Share:

  • Commercial-Grade High-Voltage Lithium Battery (358.4–716.8V, 280Ah) for High-Performance Solar Energy Storage Systems with Stable Energy Storage Capability
  • High-Capacity 280Ah High-Voltage Lithium Battery with Multi-Voltage Range 358.4-716.8V, Ideal for Commercial Energy Storage Systems in PV Industry.
  • 280Ah High-Voltage Lithium Battery (358.4-716.8V): High-Performance Energy Storage Solution for Commercial Photovoltaic Systems.
  • High-Voltage 358.4-716.8V 280Ah Lithium Battery Pack Designed for Reliable Commercial Solar Energy Storage Systems
  • Engineered for Commercial Photovoltaic Energy Storage Systems: 280Ah High-Voltage Lithium Battery with 358.4-716.8V Output for Reliable Energy Storage Solutions.
  • Commercial-Grade High-Voltage Lithium Battery (358.4–716.8V, 280Ah) for High-Performance Solar Energy Storage Systems with Stable Energy Storage Capability
  • High-Capacity 280Ah High-Voltage Lithium Battery with Multi-Voltage Range 358.4-716.8V, Ideal for Commercial Energy Storage Systems in PV Industry.
  • 280Ah High-Voltage Lithium Battery (358.4-716.8V): High-Performance Energy Storage Solution for Commercial Photovoltaic Systems.
  • High-Voltage 358.4-716.8V 280Ah Lithium Battery Pack Designed for Reliable Commercial Solar Energy Storage Systems
  • Engineered for Commercial Photovoltaic Energy Storage Systems: 280Ah High-Voltage Lithium Battery with 358.4-716.8V Output for Reliable Energy Storage Solutions.
  • 1..Safe & Reliable Performance
    LiFePO4 cathode material offers safety, long cycle life, low self-discharge (up to 6 months), no memory effect, and excellent shallow charge/discharge performance.

    2.Intelligent BMS Protection
    Includes over-discharge, over-charge, over-current, and temperature protection, with automatic charge/discharge management and cell balancing.

    3.Eco-Friendly Design
    Non-toxic, non-polluting, and environmentally friendly materials.

    4.Flexible Configuration & Wide Temperature Range
    Supports parallel connection for capacity expansion, USB/WiFi/remote upgrades, and operates efficiently from -20°C to 55°C.
Download Inquire

FAQS

Q :

What makes the installation of this module convenient?

A :

The 19-inch embedded design ensures quick and comfortable installation and maintenance.

Q :

Why is the module considered safe and reliable?

A :

It uses LiFePO4 cathode material, offering safety, long cycle life, low self-discharge (up to 6 months), no memory effect, and excellent shallow charge/discharge performance.

Q :

What protection features does the Intelligent BMS provide?

A :

The BMS includes over-discharge, over-charge, over-current, and temperature protection, with automatic charge/discharge management and cell balancing.

Q :

How does the module support flexible configuration and upgrades?

A :

Multiple modules can be connected in parallel for capacity expansion, and it supports USB, WiFi (optional), and remote upgrades, compatible with Deye inverters.

Product Information

Classification100.352KWh114.688KWh129.024KWh143.36KWh157.696KWh172.032KWh186.368KWh200.70KWh215.01KWh
Battery module specification
Configuration1P16S
Rated capacity280Ah
Rated energy14.336kWh
Rated voltage51.2V
Voltage range44.8-56.8V
Rated charge/discharge0.5C
AC internal resistance≤5mΩ
Dimension (W/D/H)376*885*238.5（±5）mm
Weight112kg
Battery rack specification
Configuration7 modules +1 BPU8 modules +1 BPU9 modules +1 BPU10 modules +1 BPU11 modules +1 BPU12 modules +1 BPU13 modules +1 BPU14 modules +1 BPU15 modules +1 BPU
Rated capacity280Ah
Rated energy100.352kWh114.688kWh129.024kWh143.36kWh157.696kWh172.032kWh186.368kWh200.70kWh215.04kWh
Rated voltage358.4V409.6V460.8V512V563.2V614.4V665.6V716.8V768V
Voltage range313.6-397.6V358.4-454.4V403.2-511.2V448-568V492.8-624.8V537.6-681.6V582.4-738.4V627.2-795.2V672-852V
Rated charge/discharge0.5C
Display7"Touch screen
BMSIncluded
CommunicationCAN
MonitoringRS485
Dimension(W/D/H)908*901*1615mm908*901*1615mm908*901*1615mm908*901*1615mm908*901*1615mm908*901*1615mm908*901*2155mm908*901*2155mm908*901*2155mm
Weight875kg1075kg1200kg1325kg1450kg1575kg1700kg1825kg1950kg
Protection degreeIP20
BMS Parameters on LCD
Cell voltageYes
Cell hight voltageYes
Cell low voltageYes
Cell temperatureYes
Charge and dicharge currentYes
Total battery voltageYes
Battery SOCYes
Fault warningYes
Protection
Short circuit protectionYes
Over current protectionYes
Over charge protectionYes
Over discharge protectionYes
Cell over voltage protectionYes
Cell under voltage protectionYes
Over temperature protectionYes
