Product Information
| PV Modules | |
| Parameter | |
| Testing Condition | STC |
| Maximum Power(Pmax/W) | 620W |
| Open Circuit Voltage(Voc/V) | 49.55 |
| Short Circuit Current(lsc/A) | 15.93 |
| Voltage at Maximum Power(Vmp/V) | 41.06 |
| Current at Maximum Power(lmp/A) | 15.10 |
| Module Efficiency(%) | 22.95 |
Adopting the 182*210mm N-Type TOPCon cells with the highest efficiency; Mechanical load tests including wind load 2400Pa and snow load 5400Pa done by TUV; Ensure the attenuation probability caused by PID phenomenon is minimized; Strict salt spray and ammonia corrosion test by TUV.
| Lithium Battery | |
| Parameter | |
| Nominal Capacity | 200Ah |
| Nominal Voltage | 48V |
| Max.Charging Current | 100A |
| Max.Discharging Current | 100A |
High Specific Energy; Support Parallel Operation; Easy Installation; Long Cycle Life.
| Inverter | |
| Parameter | |
| Inverter Output | |
| Rated Output Power | 10000W |
| Rated Output Voltage | 120/240Vac, single-phase / split-phase / three-phase(parallel) |
| Rated AC Frequency | 50/60Hz |
| Battery | |
| Battery Type | Lead-acid / Li-ion / User-defined |
| Battery Voltage Range(V) | 48V |
| PV Input | |
| Num. of MPPT | 2 |
| MPPT Operating Voltage Range | 125～425Vdc |
| General | |
| Num. of Parallel | 1～6 units |
| Dimensions | 750 x 440 x 240mm (2.46x1.44x0.79ft) |
| Weight | 42kg (92.59lb) |
| Warranty | 5 years |
Colorful touch LCD, IP65 protection degree; AC couple to retrofit existing solar system; 6 time periods for battery charging/discharging; Support storing energy from diesel generator.
