Commercial 30KW Wifi Hybrid Solar System With HJT TOPCon solar panel

Share:

  • 30KW HJT Solar Hybrid System with WiFi monitoring for efficient, real-time energy management and sustainable power solutions.
  • 30KW hybrid solar system with WiFi monitoring for efficient and smart commercial energy management.
  • 30kW hybrid solar + commercial WiFi for a reliable, efficient and scalable off-grid power and connectivity solution.
  • 30KW Hybrid Solar System with High Efficiency HJT Panels, WiFi Monitoring, Scalable Commercial Energy Solution
  • 30KW HJT Solar Hybrid System with WiFi monitoring for efficient, real-time energy management and sustainable power solutions.
  • 30KW hybrid solar system with WiFi monitoring for efficient and smart commercial energy management.
  • 30kW hybrid solar + commercial WiFi for a reliable, efficient and scalable off-grid power and connectivity solution.
  • 30KW Hybrid Solar System with High Efficiency HJT Panels, WiFi Monitoring, Scalable Commercial Energy Solution
  • ‌1. 24/7 Hybrid Energy Autonomy
    Solar-thermal/electric storage powers heating, cooling, and critical appliances during outages. Smart algorithms prioritize energy use while storing excess for nighttime or low-generation periods.

    2. Thermal Storage Efficiency
    Hybrid systems convert excess solar into thermal energy for heating/cooling, reducing grid reliance. Ideal for regions with temperature extremes or frequent power disruptions.

    3. Modular Lithium Scalability
    Expandable battery banks adapt to household needs (e.g., EV charging). Start with 5kWh, scale to 20kWh+ without replacing core components, ensuring cost-effective growth.

    4. Climate-Proof Reliability
    Operates in -30°C to 50°C with pure sine wave output. Overload protection safeguards electronics, while corrosion-resistant materials endure coastal storms or desert heatwaves.
Download Inquire

FAQS

Q :

How does 24/7 hybrid energy autonomy work?‌

A :

Combines solar-thermal and electric storage to power heating, cooling, and critical appliances during outages. Smart algorithms prioritize usage and store excess for nighttime or low solar periods.

Q :

How does thermal storage reduce grid dependence?‌

A :

Converts excess solar into thermal energy for heating/cooling, cutting grid reliance. Ideal for regions with extreme temperatures or frequent power disruptions.

Q :

Can battery capacity be expanded later?‌

A :

Yes, modular lithium systems scale from 5kWh to 20kWh+ without core replacements, enabling cost-effective growth for EV charging or higher energy needs.

Q :

Is the system reliable in extreme climates?‌

A :

Operates in -30°C to 50°C with pure sine wave output, overload protection, and corrosion-resistant build to endure coastal storms or desert heatwaves.

Product Information

PV Modules
Parameter
Testing ConditionSTC
Maximum Power(Pmax/W)620W
Open Circuit Voltage(Voc/V)49.55
Short Circuit Current(lsc/A)15.93
Voltage at Maximum Power(Vmp/V)41.06
Current at Maximum Power(lmp/A)15.10
Module Efficiency(%)22.95

Adopting the 182*210mm N-Type TOPCon cells with the highest efficiency; Mechanical load tests including wind load 2400Pa and snow load 5400Pa done by TUV; Ensure the attenuation probability caused by PID phenomenon is minimized; Strict salt spray and ammonia corrosion test by TUV.

Lithium Battery
Parameter
Nominal Capacity280Ah
Nominal Voltage460.8V
Max.Charging Current140A
Max.Discharging Current140A

Quick Customization of Electricity; Easy Installation Flexible Expansion; Emergency-Backup and On-Grid Functionality; Safety first Smart BMS system.

Inverter
Parameter
ModelMPS0030
Dimension WxDxH (mm)800x800x1900
AC(on-grid)
Rated power30kW
Rated voltage208V High-legDelta with split phase(Opt)
Rated current83A
Rated frequency50/60Hz
THDi<3%
Power factor1lagging-1leading( Settable )
AC connection3W/N/PE / 3W/N/PE Delta(Opt)
AC(off-grid)
Rated power30kW
Rated voltage208V High-legDelta with split phase(Opt)
Rated current83A
THDU≤1% linear; or≤5% nonlinear
Overload capability110% long-term
PV
MAX PV power36/72kW
MPPT voltage range250-850V
Battery
Battery voltage range250-850V
Max. charging power (kW)36/72
General data
Net weight (kg)576/607
Operation temperature (℃)-30 ~ 55
Relative humidity0~95% non-condensing
Ingress protectionIP20
Noise emission (dB)<70
Operating altitude5,000m(>3,000 Derating)
CoolingAir Cooling
Display and communication
DisplayLCD touch-screen
BMS communicationRS485, CAN
EMS communicationRS485, TCP/IP
CertificatesEN62109-1/-2, EN62477-1, EN61000-6-2, EN61000-6-4, South Africa NRS097-2-1:2017,
Pakistan & India IEC61727, IEC62116, IEC 61683
