HomeSolar PanelHJTHJT High-Efficiency 585-605W Dual Glass Solar Panels In USA Warehouse
Basic Parameters
Detail Parameters

HJT High-Efficiency 585-605W Dual Glass Solar Panels In USA Warehouse

Share:

  • 1.High Efficiency
    N-type HJT technology combines ultra-low light degradation and high conversion efficiency (typically 23.41%), maximizing energy output even in low-light conditions.

    2.Low Temperature Coefficient (-0.26%/°C)
    Ensures stable performance in high-temperature environments, minimizing power loss.

    3.SMBB & Half-Cut Design
    Reduces current transmission distance and resistive losses, optimizing cell efficiency.

    4.90% Bifaciality & Advanced Sealing
    Symmetrical bifacial structure increases rear-side energy yield, while PIB-based sealant improves water resistance and extends module lifespan.
Download Inquire

FAQS

Q :

What makes N-type HJT modules more efficient than conventional solar panels?

A :

They achieve 23.41% conversion efficiency with ultra-low light degradation, ensuring higher energy output even in low-light conditions.

Q :

How does the low temperature coefficient (-0.26%/°C) benefit performance?

A :

It minimizes power loss in hot climates, maintaining stable output even in high-temperature environments.

Q :

Why are SMBB and half-cut designs used?

A :

They reduce resistive losses and optimize current transmission, improving overall module efficiency.

Q :

What advantages does 90% bifaciality provide?

A :

It captures additional rear-side energy, while advanced PIB sealing enhances water resistance and extends lifespan.

Mechanical Parameters

Layout144Cells (6×24)
Dimensions2279 × 1134 × 30mm
Weight31.5kg
Junction boxIp68 rated (3 by pass diodes)
Packaging36pcs/box, 180pcs/20'GP, 720pcs/40'HQ

Electrical Characteristics (STC*)

Module Type: MS-72HB585590595600605
Maximum power (Pmax/W)585590595600605
Open Circuit Voltage (Voc/V)54.1254.3154.5054.7054.89
Short Circuit Current (Isc/A)13.4013.4513.5013.5513.60
Voltage at Maximum power (Vmpp/V)45.2145.4245.6345.8446.05
Current Maximum Power (Impp/A)12.9412.9913.0413.0913.14
Module Efficiency (%)22.6422.8323.0223.2223.41

Electrical Characteristics (NMOT*)

5%Maximum power (Pmax/W)614620625630635
5%Module Efficiency STC (%)23.7723.9724.1724.3824.58
15%Maximum power (Pmax/W)673679684690696
15%Module Efficiency STC (%)26.0326.2526.4826.7026.92
25%Maximum power (Pmax/W)731738744750756
25%Module Efficiency STC (%)28.2928.5428.7829.0229.26
  • 1. Standard Test Conditions [STC]: irradiance 1000W/m2; AM 1.5; ambient temperature 25°C according to EN 60904-3;
  • 2. Tolerance of Pm: 0~+5W, Measuring uncertainty of power: ±3%. Performance deviation of Voc [V], Isc [A], Vm [V] and Im [A]: ±3%.
