Product Information
| PV Modules | |
| Parameter | |
| Testing Condition | STC |
| Maximum Power(Pmax/W) | 550W |
| Open Circuit Voltage(Voc/V) | 49.64 |
| Short Circuit Current(lsc/A) | 14.00 |
| Voltage at Maximum Power(Vmp/V) | 40.90 |
| Current at Maximum Power(lmp/A) | 13.45 |
| Module Efficiency(%) | 21.29 |
Positive power tolerance (0~+5W) guaranteed; Reduced resistive loss with lower operating current; Higher energy yield with lower operating current; Reduced hot spot risk with optimized electrical design and lower operating current.
| Inverter | |
| Parameter | |
| Input Data (DC) | |
| Max. recommended PV power | 75000W |
| MPPT voltage range | 200V-1000V |
| No. of MPP trackers | 3 |
| No. of PV strings per MPp tracker | 4/4/4 |
| Output data (AC) | |
| AC nominal power | 50000W |
| Nominal AC voltage(range*) | 277V/480V three-phase |
| AC grid frequency (range*) | 50/60 Hz(45-55Hz/55-65 Hz) |
| General Data | |
| Dimensions (W/H/D) | 680/508/281mm |
| Weight | 52kg |
| Topology | Transformerless |
| Cooling | Natural convection |
| Protection degree | IP65 |
High efficiency up to 98.8%; OLED display and touch button;
AC&DC type II SPD; Smart diagnosis.
