210mm 132 Solar Cells 700-720W N-type High Efficiency Solar Panels

Share:

  • 1. Unmatched Efficiency​
    ​The Premium 210mm N-TOPCon Bifacial Solar Modules feature a 132-cell N-type monocrystalline TOPCon architecture, delivering an impressive 700-720W output. With a 10-30% higher energy yield compared to conventional P-type modules over a 30-year lifespan, these modules set a new standard for solar energy efficiency.​

    2. Cutting-Edge Technology​
    Equipped with S-TOPCon 2.0 passivation, these modules offer zero LID (Light Induced Degradation), ensuring long-term performance stability. The -0.29%/°C temperature coefficient guarantees stable high-temperature performance, while the ≥25% bifacial gain with a 70% bifaciality factor and 10W/m² low-light activation enable optimal energy generation even in less-than-ideal conditions.​

    3. Durable Design​
    Featuring a dual-glass (2.5mm+2.5mm) structure with 5400Pa wind load resistance, IP68-rated junction box, and PID-free encapsulation, these modules are built to withstand harsh environments. Their robust construction ensures reliable operation and longevity, making them a trusted choice for solar energy applications.​

    4. Comprehensive Warranty​
    Backed by a 30-year linear power output guarantee (87% at EOL) and a 25-year materials and workmanship coverage, these modules offer peace of mind and long-term value. IEC 61215/61730 certified and compatible with 1500V systems, they meet the highest industry standards for quality and safety.​
Download Inquire

FAQS

Q :

Why choose N-Type TOPCon technology?‌

A :

‌Higher Efficiency‌: N-Type TOPCon cells minimize energy loss and offer better temperature resistance compared to traditional PERC.
‌Durability‌: Lower degradation rates and enhanced reliability in harsh environments.
‌Future-Proof Design‌: Aligns with industry trends toward ultra-high power (700W+) and PVstandards.

Q :

What are the warranty and lifespan expectations?‌

A :

‌Product Warranty‌: 15-year material and workmanship coverage.
‌Power Output Guarantee‌:
25-year linear warranty with 91.8% retained output.
30-year extended options available (up to 90.3%).

Q :

How do these panels perform under real-world conditions?‌

A :

‌Low-Light Performance‌: Superior energy yield in cloudy or low-irradiance conditions5.
‌Temperature Tolerance‌: Stable output across a wide temperature range (-40°C to 85°C).
‌Mechanical Load Resistance‌: Designed to withstand heavy snow and wind loads.

Mechanical Parameters

Layout144Cells (6×24)
Dimensions2279 x 1134 x 30mm
Weight31.5kg
Junction boxIp68 rated (3 by pass diodes)
Packaging36pcs/box, 180pcs/20'GP, 720pcs/40'HQ

Electrical Characteristics (STC*)

Module Type: MS-66HB700705710715720
Maximum power (Pmax/W)700705710715720
Open Circuit Voltage (Voc/V)48.6048.7748.9449.1149.28
Short Circuit Current (Isc/A)18.3518.4018.4518.5018.55
Voltage at Maximum power (Vmpp/V)40.3540.5240.6940.8641.03
Current Maximum Power (Impp/A)17.3517.4017.4517.5017.55
Module Efficiency (%)22.5022.7022.9023.0023.20

Bifacial Output-Rearsid Power Gain

5%Maximum Power (Pmax/W)735740745750756
5%Module Efficiency STC (%)23.7023.8024.0024.1024.30
15%Maximum Power (Pmax/W)805810816822828
15%Module Efficiency STC (%)25.9026.1026.3026.5026.70
25%Maximum Power (Pmax/W)785881887893900
25%Module Efficiency STC (%)28.2028.4028.6028.7029.00
  • 1. Standard Test Conditions [STC]: irradiance 1000W/m2; AM 1.5; ambient temperature 25°C according to EN 60904-3;
  • 2. Tolerance of Pm: 0~+5W, Measuring uncertainty of power: ±3%. Performance deviation of Voc [V], Isc [A], Vm [V] and Im [A]: ±3%.
